Active infrared sensor MIRAGE
- MIRAGE
Activation&Safety
CE
The OPTEX MIRAGE is the optimal choice as an active infrared recessed mounted sensor. The sensor is designed for installation in the header of the door operator or as a built-in ceiling-mounted sensor. The OPTEX MIRAGE offers you both safety and activation on all types of automatic doors. It combines easily adjustable settings, providing maximum safety in a wide array of applications.
Features
- Easy Installation
The OPTEX MIRAGE is simple to install. All the settings are mechanically adjustable using the dipswitch and levers. The smart design ensures an engineer can easily reach the sensor should a setting require adjustment. - Safety
Safety is assured by the two rows of presence detection closest to the door. The sensor detects a person or object and holds the door open for as long as they are near the threshold area, even if they stop or pause. Of course, the OPTEX MIRAGE can also be used as a presence detection sensor only, for example, as a rear edge safety sensor. - Design
The OPTEX MIRAGE is designed for installation in the header of the door operator or as a ceiling-mounted sensor. Due to its recessed mounted design and 2 rows of presence detection, this sensor is an elegant and safe solution for installation in the ceiling of curved doors. - All Conditions
A snow mode and variable sensitivity adjustments make this sensor suitable for every application and even extreme weather conditions.
Detection Area
Specifications
Dimensions
| Mounting height A | 2000 (6' 6 3/4'') | 2200 (7' 2 5/8'') | 2500 (8' 2 7/16'') | 2700 (8' 10 5/16'') | 3000 (9' 10 1/8'') |
|---|---|---|---|---|---|
| B | 420 (1' 4 11/16'') | 470 (1' 6 3/8'') | 530 (1' 8 7/8'') | 570 (1' 10 1/2'') | 640 (2' 1'') |
| C | 850 (2' 9 5/8'') | 940 (3' 15/16'') | 1070 (3' 6'') | 1150 (3' 9 3/8'') | 1280 (4' 2 3/8'') |
| D | 1500 (4' 11 1/8'') | 1650 (5' 5 1/16'') | 1880 (6' 1 7/8'') | 2030 (6' 7 13/16'') | 2250 (7' 4 11/16'') |
| E | 2070 (6' 9 5/8'') | 2280 (7' 5 3/4'') | 2590 (8' 6'') | 2800 (9' 2 3/16'') | 3110 (10' 2 3/8'') |
| F | 210 (8 1/8'') | 230 (8 15/16'') | 260 (10 3/16'') | 280 (11'') | 310 (1' 3/16'') |
* After adjustment , turn the power OFF and ON again, be sure to walk-test all of detection areas.
* The values of the chart below is of the emitting spots , but not of the detection area.
* The actual detection area may become smaller depending on the ambiance light and the color / material of object and the floor as well as the entry speed of object.
| Model | MIRAGE |
|---|---|
| Cover color type | Black |
| Mounting height | 3.0 m (9'10'') Max. |
| Detection area | See Detection area |
| Detection method | Active infrared reflection |
| Detection angle adjustments | ±4° adjustable by 1° every one click (Deep / Shallow) |
| Detection width adjustments | 4 type selectable with adjustment shutters (Not angle adjustment) |
| Power supply | 12 to 30VAC / DC |
| Current draw | 200 mA Max. (at 12VAC) |
| Operating indicator | Green: Stand-by Red: 1st row detection active Orange: Other row detection active |
| Output | ''Form C'' relay 50V 0.3A Max. (Resistance load) |
| Relay hold time | 0.5 sec. |
| Response time | < 0.3 sec. |
| Operating temperature | -20°C to +55°C (-4°F to 131°F) |
| Weight | 260 g (9.2 oz) |
| Accessories | 1 Cable 3 m (9'10'') 1 Operation manual 1 Area adjustment tool 1 Adjustment frame |
mm (inch)
- The specifications herein are subject to change without prior notice due to improvements.
